Close view of the front control strip of a stainless wall-mount chimney range hood on a tiled wall, a few abstract lit segments on its small display and one indicator blinking, the range hood's canopy filling the upper half of the frame.

Reading a Range Hood Error Code or Blinking Light

A range hood error code may appear as letters and numbers on a display, a light that blinks in a pattern, a filter reminder that will not clear, or a beep with the fan refusing to start.

(844) 398-3217

Mon–Sat, 8am–8pm

  • 5 checks before you book
  • 5 questions that narrow it
  • 7 causes, cheapest first

Book a visit

Three short steps, about a minute.

or call (844) 398-3217

What it
usually means.

Most electronic hoods watch a handful of things: how long the filters have been in use, whether the blower is turning at the speed it was told, the heat in the canopy, whether the keypad and board are responding, and on some, the lights, the damper and a downdraft vent's lift. When something is off, the board shows a code or blinks a light in a pattern. Several are not failures at all: a filter reminder after a set number of hours, a Sabbath mode, a delay-off or heat sentry symbol, and a link to the cooking surface. No two makers use the same symbols, so a blinking lamp that asks for a filter wash on one hood may flag a heat probe on another, and only the model number settles it. Our code pages group every make's signals under families such as filter, blower, heat sensor and board, so start with the family and then the make. None of them call for opening the hood from a ladder or reaching the blower wiring; what the board points to is checked on a visit.

A technician in a plain gray work shirt stands on the kitchen floor beside a stainless wall-mount range hood in a US home, holding a small handheld airflow vane meter up under the range hood's filters, the range hood lamps lit, steam rising from a pot on the burners below, the cooking surface cropped and out of focus. The 7 causes, cheapest first

Answer these first

01

Which characters or blink pattern show, exactly?
02

Did it show up the instant power returned, after a button press, or only once the hood had been running a while?
03

Does it come with a fan that will not start, run on high, or stop?
04

Switch the breaker off for five minutes and back on: is the signal gone, and if it returns, after how long?
05

Is the model number legible on the plate you see once the filters are out?

Check these
before you book.

Range hood error code: 5 checks, and none of them costs anything.

01

Write down the characters or the blink pattern exactly, and whether they blink or hold steady.

02

Clear a filter reminder or cancel a mode as the manual shows, then see whether the code stays away.

03

Look the signal up under your make on our code pages, or in the owner's guide for that model number.

Also worth checking

  • Give the board one power reset at the panel, five minutes off, and time how long the signal takes to come back.
  • Leave the chimney cover and the blower wiring alone whatever the code says; what it points to is checked on a visit.

How soon does it need a visit?

On its own, a blinking light or a code is rarely a reason for a same-day call. Sparks, smoke, a hot smell, a breaker that drops or a hood that has shifted outrank any code: go to that page first, then book.

The causes,
cheapest first.

7 things reading a range hood error code or blinking light turns out to be, from settings that look like trouble to damper or downdraft lift out of place.

The cost guide
  1. 01 no repair

    Settings that look like trouble

    Delay-off, a heat sentry turning the fan on, Sabbath mode and a paired cooking-surface link each show their own symbol. The manual lists them and how to clear each.

    No repair: check it yourself
  2. 02 no repair

    A filter reminder

    After a set number of hours, the board reminds the owner to wash the grease filters or replace a charcoal filter. The manual shows the key press that resets the reminder.

    Fixed by range hood filter and baffle service
  3. 03 low to moderate

    Heat or grease sensor reading outside its limits

    A sensor that reads open or shorted, or one that sees too much heat, sets a code and may hold the fan on high.

    Fixed by range hood heat sensor repair See range hood fan won't turn off
  4. 04 low to moderate

    A light or power check

    Some hoods watch the LED driver or the supply voltage and set a code when a light circuit fails or power dips.

    Fixed by range hood light repair See range hood lights out or flickering
  5. 05 moderate

    Blower speed the board did not expect

    A board that watches the blower's speed sets a code when the motor stalls, slows or does not start.

    Fixed by range hood blower motor repair See range hood fan not working at any speed
  6. 06 moderate to highest

    Keypad or board check failed

    A stuck key, a cracked ribbon cable or a board that failed its own test shows a code at power-up or when a key is pressed.

    Fixed by range hood control board repair See range hood buttons or keypad not responding
  7. 07 moderate

    Damper or downdraft lift out of place

    A motorized damper or a downdraft vent that did not reach its switch in time sets a code of its own.

    Fixed by downdraft vent lift repair See pop-up downdraft vent not rising
  8. What it costs

    Every repair on the site's cost scale, side by side

    Open the cost guide

The makes
it happens on.

29 makes on this site; reading a range hood error code or blinking light can show up on any of them. Each mark opens that make's own page.

All 29 brands

Reading a Range Hood Error Code or Blinking Light,
where we come out.

9 metros, each with its own page.

All service areas

Tampa BayFL · 31 areas

OrlandoFL · 30 areas

Miami / South FloridaFL · 47 areas

New York MetroNY · 75 areas

HoustonTX · 36 areas

ChicagoIL · 50 areas

Los AngelesCA · 95 areas

San DiegoCA · 31 areas

San Francisco Bay AreaCA · 74 areas

A family cooking together under a stainless range hood in a bright kitchen.
For the heart of your home.

Questions about
reading a range hood error code or blinking light.

Is a glowing filter light a sign something broke?
No. It is a reminder after a set number of hours. Clean or replace the filters, then reset the reminder as the manual shows.
The same blink pattern returns every time the power comes back. What now?
Cutting power wipes the board's log but leaves the cause in place, so a repeat means the check failed again and the part it watches needs a look.
Can the hood still be used with a code showing?
Often yes, if the fan and the lights work and nothing smells hot. A blower or sensor code is a reason to book soon.
Do all hoods show codes?
No. Many hoods with mechanical switches show nothing at all; codes come with electronic controls. A hood without a display shows trouble only through what it does.
